India Mark III Hand Pumps

Get a Price/Quote

Product Details:

Usage Manual Water Extraction
Handle Type Lever with Holding Grip
Material Cast Iron, Stainless Steel
Diameter Connecting Rod Dia 12 mm, Riser Pipe Dia 32 mm
Application Community Water Supply, Rural Areas
Product Type India Mark III Hand Pumps
Tolerance IS:15500 - Standard Quality Tolerance
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

India Mark III Hand Pumps Product Specifications

Weight Approximately 60-80 kg (Main Assembly)
Pressure Operates at up to 45 meters water head
Shape Cylindrical
Tolerance IS:15500 - Standard Quality Tolerance
Product Type India Mark III Hand Pumps
Structure Above-Ground Pump with Below-Ground Cylinder
Material Cast Iron, Stainless Steel
Diameter Connecting Rod Dia 12 mm, Riser Pipe Dia 32 mm
Length 125 Millimeter (mm)
Application Community Water Supply, Rural Areas
Handle Type Lever with Holding Grip
Usage Manual Water Extraction

Water Outlet Height 0.6 to 1 meter above ground level
Handle Stroke 125 mm nominal
Riser Pipe Material Galvanized Iron or uPVC
Conformity Standard IS:15500 (BIS Standard)
Cylinder Material Brass or Stainless Steel
Maintenance Requirement Low, routine greasing and inspection
Cylinder Diameter 50 mm to 65 mm
Surface Finish Corrosion Resistant Paint
Life Expectancy >10 years with proper maintenance
Rod Material Mild Steel or Stainless Steel
Discharge Capacity 900-1200 liters per hour at stroke length of 125 mm and 40 strokes/minute
Installation Depth Up to 45 meters (150 feet)

Product Description

We are manufacturer & Exporter of India Mark III Hand Pumps mainly in Angola Burkina Faso Burundi Cameroon Chad Congo Congo Ethiopia Ghana Guinea Kenya Liberia Madagascar Malawi Mal Mozambique Niger Nigeria Rwanda Senegal Sierra Leone Somalia South Africa South Sudan Sudan Tanzania Togo Uganda Zambia Sri lanka New Guinea Conakry Cameron etc

India Mark III Hand Pumps Technical Details:

Brand	Apex
Installation/After Sales Service	Provided
Bore Diameter	125 mm
Operating Depth	20-45 mtr
Material	Cast Iron, Stainless Steel
Installation	After Sales Service Provided
Connecting Rod Material	MS/SS

We export to Nigeria, Uganda, Netherlands and Burkina Faso.

High Performance and Versatile Design

The India Mark III Hand Pump delivers impressive water output-900 to 1200 liters per hour-making it ideal for community and industrial usage. With its robust construction and compatibility with either brass or stainless steel cylinders, as well as galvanized iron or uPVC riser pipes, it offers versatility to suit various site conditions. The pump is engineered to function effectively at depths up to 45 meters, ensuring consistent water supply even in demanding environments.

Built for Longevity and Ease of Maintenance

Designed to last over 10 years with proper maintenance, the India Mark III Hand Pump is equipped with corrosion-resistant paint and high-quality materials, including cast iron, mild steel, and stainless steel. It requires only routine greasing and inspection to keep it functioning optimally. The pump's above-ground structure with a below-ground cylinder ensures straightforward maintenance, minimal downtime, and lasting reliability in rural and community settings.

Conforms to Stringent BIS Standards

The India Mark III hand pump is manufactured in strict adherence to IS:15500 standards laid out by the Bureau of Indian Standards (BIS). This guarantees quality, safety, and performance, giving users confidence in the product's reliability. With standard quality tolerances and uniformity in construction, water extraction remains safe and efficient, making it a trusted solution for water supply needs.

FAQ's of India Mark III Hand Pumps:

Q: How does the India Mark III Hand Pump operate and what is its water output?

A: The pump is manually operated using a lever with a holding grip. When the handle is moved, it activates the internal piston inside the below-ground cylinder, drawing up water. It provides a discharge capacity of 900-1200 liters per hour at a recommended rate of 40 strokes per minute with a 125 mm stroke length.

Q: What is the maximum installation depth for the India Mark III Hand Pump?

A: This hand pump can be installed at depths of up to 45 meters (150 feet), making it suitable for drawing groundwater from deep sources in rural and community settings.

Q: When should routine maintenance be performed on the India Mark III Hand Pump?

A: Routine maintenance, such as greasing moving parts and conducting inspections, should be carried out periodically-ideally every few months or as recommended by local service guidelines-to ensure optimal performance and to extend the pump's service life beyond 10 years.

Q: Where is this hand pump best installed and for which applications is it most suitable?

A: The India Mark III Hand Pump is best suited for installation in rural areas, community water supply projects, and industrial sites where reliable manual water extraction is required. It is also widely used by distributors, exporters, manufacturers, suppliers, and wholesalers across India.

Q: What materials are used in constructing the India Mark III Hand Pump and why are they chosen?

A: The pump uses cast iron and stainless steel for structural durability, brass or stainless steel for the cylinder, and mild steel or stainless steel for the rods. Riser pipes are made of galvanized iron or uPVC, all treated with a corrosion-resistant surface finish for longevity and reliability in harsh environments.

Q: How does adherence to IS:15500 (BIS Standard) benefit users?

A: Compliance with IS:15500 ensures the pump meets high standards for quality, safety, and performance. This guarantees consistency in construction, safety for community use, and reliable water extraction in various conditions.
