Afridev Well Hand Pumps
Product Details:
- Weight Approx. 60-70 kg
- Shape Rectangular Stand, Cylindrical Pump Body
- Diameter Cylinder: 50 mm; Riser Pipe: 32 mm
- Usage Manual Water Extraction from Wells
- Structure Heavy Duty with Riser Pipe and Plunger Assembly
- Handle Type Ergonomic, Long Handle
- Pressure Up to 30 meters dynamic water level
- Click to View more
X
Afridev Well Hand Pumps Product Specifications
- Stainless Steel
- 3 Meter (m)
- High Tolerance for Rural Use
- Heavy Duty with Riser Pipe and Plunger Assembly
- Afridev Well Hand Pumps
- Community and Rural Water Supply
- Manual Water Extraction from Wells
- Ergonomic, Long Handle
- Up to 30 meters dynamic water level
- Cylinder: 50 mm; Riser Pipe: 32 mm
- Rectangular Stand, Cylindrical Pump Body
- Approx. 60-70 kg
- 0.80 m above ground level
- Up to 0.33 liter/sec at 40 strokes/min
- Sturdy Flanged Pedestal for Firm Mounting
- 10 to 45 meters below ground level
- Brass or Stainless Steel
- Designed for Easy Maintenance and Part Replacement
- Corrosion Resistant Paint
- 125 mm (5 mm)
- Recommended for up to 300-400 people/day
Product Description
We are manufacturer & Exporter of Afridev Well Hand Pumps mainly in Angola Burkina Faso Burundi Cameroon Chad Congo Congo Ethiopia Ghana Guinea Kenya Liberia Madagascar Malawi Mal Mozambique Niger Nigeria Rwanda Senegal Sierra Leone Somalia South Africa South Sudan Sudan Tanzania Togo Uganda Zambia Sri lanka New Guinea Conakry Cameron etc
Afridev Well Hand Pumps Technical Details:
|
Connecting Rod Diameter |
10 mm |
|
Water Level Setting Depth |
Up to 45 Meter |
|
UPVC Riser Pipe Length |
3 mtr |
|
Stroke Length |
225 mm |
|
Plunger Rod Material |
Stainless Steel |
|
Inner Bore Diameter |
100 mm |
|
Discharge |
900 - 1200 Litres/Hour |
We export to Nigeria, Uganda, Netherlands and Burkina Faso.
Rugged and Reliable Community Water Solution
Afridev Well Hand Pumps are specially designed for high durability and consistent performance in challenging rural environments. With heavy-duty construction, corrosion-resistant coating, and a robust pedestal, the pump stands up well to frequent use and varied climate conditions. Its cylinder, available in either brass or stainless steel, ensures longevity even with daily operation by hundreds of users.
Easy Maintenance and Part Replacement
A key feature of the Afridev hand pump is its user-friendly design, enabling straightforward maintenance and rapid part replacement. The modular riser pipe and plunger assembly allow local technicians or trained users to carry out repairs quickly, minimizing downtime and keeping water running smoothly for the community.
Optimal for Industrial and Rural Water Needs
With the ability to extract water manually from wells at depths of up to 45 meters and operating under dynamic water levels of up to 30 meters, the Afridev pump delivers steady performance in both industrial sites and rural communities. Its recommended user capacity and efficient discharge rate make it an excellent long-term investment for communal water access.
FAQ's of Afridev Well Hand Pumps:
Q: How is the Afridev Well Hand Pump installed and at what depth can it be operated?
A: The Afridev hand pump is installed into wells with depths ranging from 10 to 45 meters below ground level. Its design accommodates dynamic water levels up to 30 meters, making it fit for most rural and community water supply needs. Professional technicians are typically recommended for initial installation to ensure optimal functioning.Q: What makes the Afridev Well Hand Pump suitable for use in rural and community settings?
A: With a sturdy, heavy-duty structure, high tolerance for challenging usage, and parts made of corrosion-resistant materials, the Afridev pump is engineered to withstand frequent operation and harsh environmental conditions. It is also capable of supporting water needs for up to 300-400 people per day, making it ideal for schools, villages, and communal sites.Q: When does the Afridev hand pump require maintenance, and how is it maintained?
A: Routine inspection of the Afridev hand pump should be performed every few months to ensure all components are functioning properly. Its design allows for easy access to parts, so maintenance tasks such as plunger or riser pipe replacement can be performed locally with minimal disruption to water supply.Q: Where can Afridev Well Hand Pumps be used most effectively?
A: Afridev Well Hand Pumps are most effective in rural areas, small towns, or industrial sites that require a reliable manual water extraction solution. Due to their robust construction and adaptability to varying depths, they are well-suited for schools, healthcare centers, and agricultural communities.Q: What is the process for extracting water using the Afridev hand pump?
A: Water extraction is done manually by operating the ergonomic, long handle in repeated strokes. At a rate of 40 strokes per minute, the pump delivers up to 0.33 liters of water per second through a spout 0.8 meters above ground, making water collection straightforward and efficient for users of all ages.Q: What are the benefits of using a hand pump with brass or stainless steel cylinders?
A: Cylinders made of brass or stainless steel provide excellent resistance to corrosion and ensure a long service life, especially in aggressive or mineral-rich groundwater conditions. This durability minimizes maintenance frequency and ensures a consistent, safe water supply over time.Tell us about your requirement
